SeGreta Plus

The patented security door with safety boxes

SeGreta security door looks like a normal security doors, but inside of it you can have two safety boxes (one on the top and/or one of the hinge side) where you can hide your documents and jewels, because they are completely invisible and not accessible.

SeGreta Plus has the same features of SeGreta, but the standard equipment is with the top safety box, the magnetic defender Key Protector, and the innovative locking system with Multilock Interactive® cylinder, equipped with 1 master key + 5 user coded key (2 keys open both the door and the safety box, 3 keys open only the door).

FIND A PARTNER
ASK FOR INFO ABOUT THIS PRODUCT

Security for windows

Thermal insulation
1,13 - 1,26 W/m²K
Acoustic insulation
30-31 dB
Anti-intrusion
Class 3
Air permeability
Class 3
Resistance to wind load
Class 5
Watertightness
Class 9
Installation
Security doors for external installation
Acoustic insulation notes
30 dB with external panel 4mm thick 31 dB with external panel 10mm thick
Thermal transmittance notes
1,13 W/m²K with external panel 20mm thick 1,26 W/m²K with external panel 4mm thick
  1. Subframe made with 20/10 thick galvanized steel with nr. 12 anchors to wall
  2. Frame made with 20/10 thick galvanized steel, painted brown Ral 8017 and complete with plastic covers, gasket and footers
  3. Adjustable hinges on 3 axes with brown hinge covers
  4. Doorleaf made of two galvanized steel sheets16/10 thick. Gasket in the perimeter of the leaf
  5. Thermal insulation with high density polyurethane.
  6. Upper safety box* with a European cylinder locking system with a key different from the one of the main entrance locking system
  7. Lateral safety box* (optional) with European cylinder locking system with a key different from the one of the main entrance locking system
  8. Wide-angle peephole
  9. Security locking system with core with European cylinder Mul-t-lock Interactive® for the security door and the safety box, equipped with 1 master key + 2 keys opening both the safety box and the security door + 3 keys opening the security door only. Patented Rolly defender, drill-proof, dust-proof
  10. Opening limiter and inside service lock
  11. Lateral deadbolts
  12. Handle set in aluminium silver colour (inside handle + outside fixed knob. Upon request, outside turning knob or inside+outside handle)
  13. Weatherstrip bar or bottom rebate of the door threshold
  14. 5 fixed deadbolts on the hinge side



*Dimension f the safety box cm. 35,5 x 24 x 2,63 deep

European cylinder Yale

European locking system with a set of 5 user keys. (outside: cylinder, inside: service lock with little knob).

European cylinder locking system 1+3

European cylinder locking system with 1 red master key + 3 keys with card duplication. The lock is equipped with a hardened steel drill-proof plate. Outside, drill-proof defender.

Top security European Cylinder EVVA 3KS

3KSplus is the most resistant mechanical locking system, due to its unique, patented, springless operating principle. Unlike conventional cylinders, in 3KSplus the locking elements move along the curves on the key and are not driven against a spring force. The reversible key have a unique rounded tip and overlapping curve millings, that practically rules out key manipulation within the locking system. The additional coding also provides highest security. 3KS ensures picking and scanning protection,drilling and plug pulling protection. It's provided with 3 or 5 key plus a disposable cyclinder to change after installation.

High security European Cylinder EVVA ICS

ICS offers different locking technologies for high protection: the time-tested curve system, the durable length profi le and distinctive track system with internal recesses. It ensures anti-picking and scanning protection, drilling and plug pulling protection. It is produced in modular design and can be adapted to the door requirements directly on-site. The high-quality nickel silver alloy make the key durable and resistant. The concealed, inner recesses make unauthorised duplication of keys practically impossible. It's provided with 3 or 5 key plus a disposable cyclinder to change after installation.

Inside black squared handle

Inside black squared handle

External squared black knob

External squared black knob

Handle kit DibiDoku

Handle kit DibiDoku

Dibidoku knob

Dibidoku knob

Handle kit Evotech

Handle kit Evotech

Evotech knob

Evotech knob

Handle kit Poker

Handle kit Poker

Poker knob

Poker knob

Handle kit Quadrata

Handle kit Quadrata

Squared knob

Squared knob

Blip

Blip

Sensunels - Fluke

Sensunels - Fluke

Sensunels - Korpo

Sensunels - Korpo

Sensunels - Sike

Sensunels - Sike

Sensunels - Twist

Sensunels - Twist

Long Handle

Long Handle

Squared longhandle in stainless steel

Squared longhandle in stainless steel

Round black longhandle

Round black longhandle

Squared black longhandle

Squared black longhandle

Standard:

cm 80-85-90 x H 200-210

Out of standard:

cm W from 70 to 100 x H from 190 to 230 (steps of 1 cm)

Push opening.


Installation solutions

Complete file

Download the PDF with the technical drawings of all installation solutions of frames and subframes proposed by Di.Bi.

DOWNLOAD PDF
Show all

Documents download

Price list
Products guarantee
Checklist for taking dimensions
Technical drawings
  • Price list - Steel Frames 413.12 KB
    Price list August 2021. Update January 3rd 2022 + 5% DOWNLOAD
  • Price list - Alu frames 84.87 KB
    Price list August 2021. January the 3rd 2022 +5% on the overall price list DOWNLOAD
  • Steel Frames price list 2020 396.82 KB
    Steel Frames price list (Rev. September 2020) DOWNLOAD
  • Aluminium Frames price list 2014 229.33 KB
    Aluminium Frames price list 2014 DOWNLOAD
  • Form Installation Check 571.32 KB
    Form for the Installation Check - to be used after the installation DOWNLOAD
  • Guarantee for Di.Bi. products 25.95 KB
    Guarantee statement for all Di.Bi. products (rev. July 2018) DOWNLOAD
  • Checklist for taking dimensions of security doors 2.34 MB
    Checklist for a proper procedure for taking dimensions of security doors (rev.2014-05-07) DOWNLOAD
  • SeGreta technical drawings 351.12 KB
    Technical drawings for SeGreta leaf with position of the safety boxes. DOWNLOAD
Instruction manuals
  • Instruction manual for the installation of frames on 1 leaf security doors 1.70 MB
    Instruction manual for the installation of frames on subframes of 1 leaf Di.Bi. security doors (rev. 07/2020) DOWNLOAD
  • Assembly instructions for frame sol. B (with top window) 310.13 KB
    DOWNLOAD
  • Instruction manual for security door handle kit 2.18 MB
    Instruction manual for Di.Bi. security doors handle kit (rev. 07/2020) DOWNLOAD
  • Instruction manual for the installation and adjustment of security doors with regular hinges 1.22 MB
    Instruction manual for the installation and adjustment of Di.Bi. security doors with regular hinges (rev. 07/2020) DOWNLOAD
